GAMMA Wall Mount Offset Back Plate Hinge
Regular price
$48.50
Couldn't load pickup availability
Product Overview
| 5 Degree Preset | No |
| Adjustable | No |
| Back Plate | Offset Back |
| Glazing Thickness (in.) | 3/8 to 1/2 |
| Material | Brass |
| Max Door Weight (lbs.) (2 Hinges) | 110 |
| Max Door Weight (lbs.) (3 Hinges) | 140 |
| Max Door Width (in.) (2 Hinges) | 32 |
| Max Door Width (in.) (3Hinges) | 32 |
| Mount Type | Wall Mount |
| Self-Centering | Yes |
| Width (in.) | 2 |
| Height (in.) | 3.5 |
The Future Glass Gamma Wall Mount Offset Back Plate Hinge is made from high-quality solid brass. Unlike other brands, Future Glass hinges feature a fixed rubber gasket designed to reduce door slippage. The unique square cut-out design alleviates the need for traditional mouse ear glass panel cut-outs. Eliminating the need to remove the backing plate completely when fixing the hinge to the door panel allows for significantly faster and easier installation. The images provided are of the actual product or a close representation. Colors may vary, depending on your screen settings.
- Compatible with FG Glass Panels
- Solid brass construction
- Total allowable door weight (2 hinges) - Up to 110 lbs. (50 kg) and maximum door width of 32"
- Use with 3/8" (10 mm) or 1/2" (12 mm) thickness tempered safety glass
- Fast Fit technology easy slide-on hinge
- Fixed gaskets to prevent door slippage
- Available in several finishes
Substitutions: PEGASUS - PEG-0B90-
Guidelines and Templates:
